| Event: | The 2006 Ready Race of Asia |
| Location: | Trang , Thailand |
| Trang RC Raceway , Tungjake Sport Stadium, Trang 92000 | |
| Date: | 8-10 December 2006 |
| Track: | Permanent outdoor asphalt |
| Class: | Stock 19 Turn Electric Touring 1/10 car |
| Open Modified Electric Touring 1/10 car | |
| Electricity: | 220V (type A) 2 flat blade electric plug |
| Entry Fee: | THB 2,000 per driver per class |
| Race Organizer: | Mr.Vit Leelawat |
| Trang RC Raceway | |
| Municipal of Trang City | |
Even Organizer: |
TQ-Racing Thailand co..Ltd |
:: TOP |
|
| This Race Schedule is a Provisional Race Schedule as for your planning. The Actual Race Schedule will be posted at the race, kindly recheck again . | |
| Please find below for the following for both classes; | |
| • 5 minutes race for all. | |
| • Three rounds of each group for Free Practice. | |
| • Two rounds of each group for Control Practice, the best result will be regroup in Qualify Session. | |
| • Five rounds of each group for Qualify Session (after 4 th Qualify will be regroup for 5 th Qualify) | |
| • The best result of total 5 qualifying will be considered into Main A, B, . In Final Race | |
| • 3 rounds for Final in Main A will be counted by point. Finish in 1 st get 10 point and after 9, 8, 7, The best 2 from 3 results will be selected for the Winner. If the winner point is equally, the 3 rd round of Final will be considered for the Winner. | |
| • Main B and C will race in 2 rounds and combine the results for the Winner. Main D, E and F will race only one time for the Winner. | |
| Friday 8th December 2006 | |
| • 07.00 07.30 Paddock opens / Drivers registration | |
| • 08.00 13.50 Free Practice in Groups | |
| • 14.00 17.50 Control Practice in Groups / Track Closed | |
| Saturday 9th December 2006 | |
| • 07.30 Paddock opens / Transmitter deposit | |
| • 07.40 08.30 Handout Super Stock 19T Motors | |
| • 08.30 17.00 Qualify Session 1-4 | |
| • 17.00 Deposit Super Stock 19T Motors | |
| • 17.15 Regrouping result for 5 th Qualify/Track Closed | |
| Sunday 10th December 2006 | |
| • 08.00 Paddock opens / Transmitter deposit | |
| • 08.00 08.50 Handout Super Stock 19T Motors | |
| • 09.00 11.00 Qualify Session 5 | |
| • 11.30 16.15 Final Rounds | |
| • 19.00 Driver party at Thummarin Thana Hotel / Prize Presentation | |
Regulations (additional regulations may be different from IFMAR as follows) |
:: TOP |
| 1. Car | |
| 1.1 Cars must be Touring Car 4 doors which available in the market and scale 1/10 such as Sedan Car. | |
| 1.2 Tyres, motor and battery cannot exceed over the car when view from top. | |
| 1.3 The mirror of car must be used bright, clear and smoke color. | |
| 1.4 The body of the car must be paints. | |
| 1.5 The Headlight in front of the car must be painted or posted by sticker. | |
| 1.6 The body can be decorated by wing or spoiler only. | |
| 1.7 Body beside the car must be over the doors, behind the car must wide more than 35mm. | |
| 1.8 On the body of the car cannot drill a hole, except the following; antenna pipe, body mount and transponder, which are not over 10mm. | |
| 1.9 Dimension: Maximum width without body 190mm | |
| • Maximum width with body 200mm | |
| • Maximum wheelbase 273mm | |
| • Minimum height 115mm | |
| • Minimum weight (incl. Transponder) 1500g | |
| • No Minimum ride height | |
| 2. Chassis | |
| 2.1 Chassis must have 4 independent suspensions (which separate) | |
| 2.2 Chassis in front must not be used hard plastic. | |
| 3. Bumper | |
| 3.1 Bumper can be used or not used, however should be safe. | |
| 3.2 Front and rear bumper cannot exceed over the body. | |
| 4. Wing | |
| 4.1 Wing or spoiler can be decorated only one at the rear of the car. | |
| 4.2 Wing or spoiler must be installed to the body, not to the chassis. | |
| 4.3 Dimension: Maximum wing chord 40 mm | |
| • Maximum wing width 190 mm | |
| • Wing endplates maximum 40 x 25 mm | |
| 5. Tyres / Additive and Wheels | |
| 5.1 The Tyre-Additive can be used for this event. | |
| 5.2 Tyres and wheels hand out from organizer. Only 3 sets can be used. | |
| 5.3 For A-main, drivers will receive 2 new sets of assembled tire and have to use those 2 sets of them for Finals (can not use old 3 sets). | |
| 6. Drive System | |
| 6.1 Four wheel drive only for this event. | |
| 6.2 The use of Multiple-speed (2 speeds) transmissions and slipper clutch is not allowed. | |
| 7. Batteries | |
| 7.1 Battery must be Sub-C size, Ni-Cd or Ni-MH. | |
| 7.2 Each cell of battery must be 1.2V and maximum 6 cells/pack = 7.2V. | |
| 7.3 Battery must be available in the market and has a brand name. | |
7.4 Battery aids for servo can be installed, but not function with any systems of driving power. |
|
| 8. Motors | |
| 8.1 Super Stock 19T Motor | |
| a.) only one HANDOUT 19T MOTOR is allowed to use by each driver for this event. All drivers will receive handout motor in the morning and must return to race organizer daily at the end of the race. Anyone who fails to return the motor will result Out of the Race. | |
| b.) Motor brushes can be changed but the eyelet must be installed by screw only Soldering is not allowed to any part of brushes. | |
| c.) Motor Comm. can be maintenance by Comm. Lathe. | |
| d.) Wires of ESC (Electronic Speed Control) can be soldered to motor. | |
| e.) Diode, Capacitor and Power booster are allowed. | |
| Any modifications that were not described in the regulations (#8.1) are not allowed. | |
| 8.2 Modified Motor | |
| a.) Motor will not be supplied by the race organizer. | |
| b.) No limited of turns and type of brushes. | |
| c.) Motor Comm. can be maintenance by Comm. Lathe. | |
| d.) Wires of ESC (Electronic Speed Control) can be soldered to motor. | |
| e.) Diode, Capacitor and Power booster are allowed. | |
| f.) Motor must be available in the market and has a brand name. | |
| All cars must be within the specifications at any time of the race. (either before or after the run!). | |
--------------------------------------------------------------------------------------------------------------------------------------------------- |
